Portable EV Charger GB/T - Schuko (220V), 6-16A, 3.5kW, 1-Phase, 5m

Portable charger for electric vehicles, with GB/T plug, adjustable current 6A-16A, max. 3.5kW, single-phase, with LED display and touch buttons, IP66, with 5m cable.


Features:
The portable charger allows charging electric vehicles from an AC grid with up to 3.5kW power.
GB/T EV connector (Chinese standard) and Schuko plug.
5-meter long charging cable.
Convenient LED display and two touch buttons.
Touch buttons allow selecting the charging current (6-16A) and the charging start time (from 30 min to 5 hours).
Due to its low weight, it is convenient to transport.


Technical data:
Adjustable charging current: 6A-16A (1-phase).
Max. charging power: 3.5kW.
Operating voltage: 220V AC, 50/60Hz.
Cable length: 5m.
EV plug type: GB/T 20234 (Chinese standard), 7 pins.
Power connection: Schuko, 16A, 200-250V, 2 pins.
Cable dimensions: 3x2.5mm²+1x0.75mm² (EN50620).
Size: 220 x 60 x 100 mm.
Safety class: IP66 for charger, IP54 for plug.
Protection against: overheating, overvoltage, overload, voltage fluctuations, short circuit, overvoltage, leakage; earthing.
Operating temperature: -25°C ~+50°C.
Operating humidity: <95% RH (non-condensing).
Certificates: CE.
Color: black.


Warranty: 24 months.
