Wall mounted motion sensor Theben T1010506 S180 (180°, black)
zoom_out_map
Wall mounted motion sensor Theben T1010506 S180 (180°, black)

Wall mounted motion sensor Theben T1010506 S180 (180°, black)

€ 36,30
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Operating voltage230 V AC
  • Frequency50 Hz
  • Stand-by consumption~0.9 W
  • Light measurementMixed light measurement
  • Number of channels1
  • ColourBlack (similar RAL 9005)
  • Switching outputLight
  • Installation typeWall installation
  • Setting range brightness5 – 1000 lx
  • Switching capacity10 A at 230 V AC, cos φ = 1, 6 A at 230 V AC, cos φ = 0.6, 3 AX at 230 V AC, cos φ = 0.3
  • Detection angle180°
  • Installation height2 – 4 m
  • Light switch-off delay1 s-20 min
  • Incandescent/halogen lamp load2300 W
  • Energy saving lamps250 W
  • Inrush currentmax. 300 A / 200 µs
  • LampsIncandescent/halogen lamps, fluorescent lamps, Energy saving lamps, LEDs
  • Remote controlled
  • Ambient temperature-25°C ... 45°C
  • Impact resistanceIK04
  • Protection classII
  • Type of protectionIP 55
