Battery Power Bubble Premium PBP1209 (9Ah, 12V)

Power Bubble Premium PBP1209 is a reliable 12V lead-acid battery designed for various systems requiring a stable power source. With a nominal capacity of 9Ah, it is ideal for uninterruptible power supplies (UPS), security systems, emergency lighting devices, and telecommunications equipment. This battery ensures long-lasting and efficient operation in professional environments.

Product Information

Key Features

• Cell Count: 6
• Voltage: 12V
• Nominal Capacity: 36W@15min-rate to 1.67V per cell @25C
• Reference Capacity: C10 8.5Ah, C20 9.0 Ah
• Weight: 2.35 kg (± 5%)
• Dimensions: 151 x 65 x 94 mm
• Terminals: F2 (optional)
• Made From: A.B.S. UL94-HB, UL94-V0 (optional)

Electrical Characteristics

• Internal Resistance: ≤ 22 mΩ
• Max. Discharge Current: 90A (5 sec.)
• Short Circuit Current: 450A
• Max. Charge Current: 2.7A
• Standby Use Voltage: 13.7V~13.9V @ 25°C (Temperature Compensation: -3mV/'C/Cell)
• Cycle Use Voltage: 14.6V~14.8V @ 25°C (Temperature Compensation: -4mV/°C/Cell)

Performance Characteristics

• Service Life: 8 years
• Operating Temperature Range: Discharge: -20°C~60°C; Charge: 0°C~50°C; Storage: -20°C~60°C
• Normal Operating Temperature Range: 25°C ± 5°C
• Self-Discharge: RITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25°C, after which recharging is recommended. The monthly self-discharge rate is less than 3% at 25°C. Before use, batteries should be charged.

Downloads / Certificates

📄CE Declaration

📄Specification
