Circuit breaker Legrand S301 TX3 403434 (1P, 16A, 6kA, AC)
zoom_out_map
Circuit breaker Legrand S301 TX3 403434 (1P, 16A, 6kA, AC)

Circuit breaker Legrand S301 TX3 403434 (1P, 16A, 6kA, AC)

€ 4,00
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Built-in depth44 mm
  • Release characteristicC
  • Number of poles (total)1
  • Number of protected poles1
  • Rated current16 A
  • Rated voltage230 V
  • Rated insulation voltage Ui500 V
  • Rated impulse withstand voltage Uimp4 kV
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V6 kA
  • Voltage typeAC
  • Frequency50-60 Hz
  • Current limiting class3
  • Flush-mounted installationYes
  • Concurrently switching neutral conductorNo
  • Pollution degree2
  • Additional equipment possibleYes
  • Width in number of modular spacings1
  • Degree of protection (IP)IP20
  • Explosion-proofNo
  • Width17.8 mm
  • Height88 mm
  • Depth77.8 mm
  • Degree of impact strength (IK)IK02
  • Storage temperature-40-70 °C
  • Nominal voltage240-415 V
  • Electric supplying directionBy the top or bottom
  • Terminal marking indicationNo
  • ColourGrey
  • RAL-number7035
  • Halogen freeYes
  • Connection typeScrewed terminal, Busbar and cable
  • Label space/information surfaceYes
  • Mounting methodDIN rail
