Battery Power Bubble PB12023 (2.3Ah, 12V)

In stock: Yes

€ 11,30

Delivery is always on time

Order product today

And we will send your order tomorrow.

Quantity

General
Cells per unit6
Voltage per unit12V
Nominal Capacity2.3Ah@20hour-rate to 1.75V per cell@25C
Weight0.85 kg (± 5%)
Internal resistance≤ 70 mΩ
TerminalF1
Max. discharge current120A (5 sec)
Short circuit current120A
Design life6-8 years
Max. charging current0.69A
Reference capacityC3 1.73Ah C5 1.96 C10 2.15Ah C20 2.30 Ah
Standby use capacity13.7V~13.9V @ 25°C Temperature Compensation: -3mV/'C/Cell
Cycle use voltage14.6 V~14.8V @ 25°C Temperature Compensation: -4mV/°C/Cell
Operating temperature rangeDischarge: -20'C~60C Charge: 0°C~50C Storage: -20'C~60°C
Normal operating temperature range25C+5C
Self dischargeRITAR Valve Regulated Lead Acid (VRLA) batteries can be stored for up to 6 months at 25°C and then recharging is recommended. Monthly Self-discharge ratio is less. than 3% at 25'C Please charge batteries before using
Container materialA.B.S. UL94-HB, UL94-V0 Optional
