Residual current relay with automatic circuit breaker Legrand 411053 (C, 32A, 2P, 30mA, 230V).

Description

Legrand 411053 is a residual current circuit breaker with overcurrent protection (RCBO) for electrical circuits, designed to reliably protect against overcurrents, short circuits, and dangerous residual currents. This RCBO module, with a rated residual current of 30 mA, ensures fast and effective protection of people against electric shock. The device is suitable for use in low-voltage electrical networks, mounted according to standard DIN rail systems, ensuring wide compatibility with common distribution boards.

Specifications

• Number of poles: 2P
• Rated voltage: 230 V AC
• Rated current: 32 A
• Rated residual current: 30 mA (residual current protection)
• Residual current type: A (detects AC and pulsating DC residual currents)
• Tripping characteristic: C (designed for general purpose circuit protection)
• Breaking capacity: 10 kA (ensures safe circuit disconnection in case of high short circuits)
• Width: 2 modular spaces (installation on standard DIN rail systems)
• Built-in depth: 44 mm
• IP rating: IP20 (protection against solid particles)
• Connectable conductor cross-section (solid wire): 0.75-16 mm²
• Connectable conductor cross-section (flexible wire): 0.75-10 mm²

Manufacturer

🔗 Manufacturer's link

Documents / Certificates

🔗 Datasheet

Frequently Asked Questions (FAQ)

What is the main purpose of the Legrand 411053 RCBO?

The Legrand 411053 RCBO is designed to protect electrical circuits from overcurrents, short circuits, and dangerous residual currents. It ensures the safety of both electrical installations and people.

What does a 30 mA rated residual current mean?

A 30 mA rated residual current means that the device will automatically disconnect power if the earth leakage current exceeds this limit. This is a standard sensitivity for direct protection against electric shock.

Is the Legrand 411053 compatible with standard DIN rail systems?

Yes, this RCBO module, with a width of 2 modular spaces, is compatible with and installed according to standard DIN rail systems, allowing it to be integrated into common distribution boards.
