Circuit breaker with residual current relay Legrand 411002 (16A, 1P+N, 230V, 30mA, RCBO)

Description

The Legrand 411002 is an RCBO (Residual Current Breaker with Overcurrent protection), designed for the protection of low-voltage electrical networks. This RCBO model (1P+N, 230V) features a 16 A rated current and a 30 mA AC type residual current device, ensuring immediate disconnection in case of a fault and providing protection against electric shock. The device complies with low-voltage installation requirements, ensuring reliable circuit safety.

Specification

• Type: Automatic Circuit Breaker with Residual Current Relay (RCBO)
• Number of Poles: 1P + N
• Rated Voltage: 230 V
• Rated Current: 16 A
• Residual Current Device Sensitivity: 30 mA
• Residual Current Device Type: AC

Manufacturer

🔗 Manufacturer's Link

Frequently Asked Questions (FAQ)

How is the Legrand 411002 installed?

The Legrand 411002 model is installed according to standard DIN systems, ensuring compatibility with common distribution boards.

What is the significance of a 30 mA residual current device?

A 30 mA sensitive residual current device ensures rapid circuit disconnection in case of a dangerous leakage, thereby protecting people from electric shock.
