Contactor Hager ESC227 (1P, 25A, 230V, 1NO+1NC, 1 module)
zoom_out_map
Contactor Hager ESC227 (1P, 25A, 230V, 1NO+1NC, 1 module)

Contactor Hager ESC227 (1P, 25A, 230V, 1NO+1NC, 1 module)

€ 33,20
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Type of contacts1NC + 1NO
  • Number of contacts2
  • Rated current25 A
  • Category of useAC-7a / AC-7b
  • Command voltage AC230 V
  • Command voltage DC0 V
  • Rated operational voltage Ue230 V
  • Rated insulation voltage Ui250 V
  • Rated impulse withstand voltage Uimp4,000 V
  • Frequency50 Hz
  • Number of modules1
  • Cross-section flexible conductor1–6 mm²
  • Cross-section rigid conductor1–10 mm²
  • Nominal tightening torque1.20 Nm
  • Number of NO contacts1
  • Number of NC contacts1
  • Manual switchNo
  • Mechanical endurance100,000 operations
  • Electrical endurance30,000 cycles
  • Total power loss at In2.50 W
  • Inrush power absorbed10.70 VA
  • Operating temperature–10 to +50 °C
  • Storage/transport temperature–40 to +80 °C
  • Height83 mm
  • Width17.85 mm
  • Depth60 mm
