Contactor Hager ESC340 (3P, 40A, 230V, 3NO, 1 module)
zoom_out_map
Contactor Hager ESC340 (3P, 40A, 230V, 3NO, 1 module)

Contactor Hager ESC340 (3P, 40A, 230V, 3NO, 1 module)

€ 68,40
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Type of contacts3NO
  • Number of contacts3
  • Rated current40 A
  • Acceptable current rating (AC3)25 A
  • Category of useAC-7a / AC-7b
  • Command voltage AC230 V
  • Command voltage DC0 V
  • Rated operational voltage Ue400 V
  • Rated insulation voltage Ui440 V
  • Rated impulse withstand voltage Uimp4,000 V
  • Frequency50 Hz
  • Number of modules3
  • Cross-section flexible conductor1.5–16 mm²
  • Cross-section rigid conductor1.5–25 mm²
  • Nominal tightening torque—
  • Number of NO contacts3
  • Number of NC contacts0
  • Manual switchNo
  • Mechanical endurance100,000 operations
  • Electrical endurance30,000 cycles
  • Total power loss at In11.10 W
  • Inrush power absorbed62.50 VA
  • Operating temperature–10 to +50 °C
  • Storage/transport temperature–40 to +80 °C
  • Height85 mm
  • Width54 mm
  • Depth60 mm
