Flush-mounted modular enclosure Hager FWU72S (168 modules, IP30)
zoom_out_map
Flush-mounted modular enclosure Hager FWU72S (168 modules, IP30)

Flush-mounted modular enclosure Hager FWU72S (168 modules, IP30)

€ 509,30
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order on monday.
Quantity

  • General
  • Number of conduit inlets4
  • Outdoor usageSuitable for outdoor usage: No
  • Mounting typeFlush mounting, Hollow wall
  • Rated current125 A
  • Number of rails14
  • Number of rows7
  • Number of section in width2
  • With lockNo
  • Neutral terminal blockYes
  • Earthing terminal blockYes
  • Mounting plateNo
  • Number of modules168
  • Main switch protectionNo
  • With conduit inletsYes
  • Height1,153 mm
  • Width603 mm
  • Depth125 mm
  • Built-in height1,102 mm
  • Built-in width560 mm
  • Built-in depth112 mm
  • Number of width units24
  • Number of cabinet doors1
  • Handle typeHinged pattern handle
  • Transparent door/coverNo
  • MaterialSteel
  • RAL code9010
  • ColourPure white
  • Protection classIsolation class II
  • Impact resistance (IK)IK09
  • Ingress Protection (IP) classIP30
  • Locking typeWithout lock
  • Glow wire test850 °C
