Floor box 4mod. Legrand 089752 (brushed brown steel)

Description

The Legrand 089752 (brushed brown steel) is a 4-module floor box, designed for use in commercial and industrial environments. This device features IK08 impact resistance, ensuring high protection against mechanical damage. The floor box meets low-voltage installation requirements, ensuring a reliable and safe electrical connection.

The design allows for the integration of LED lighting, enhancing functionality. Separate back boxes (models 081988 and 080188) are required for installation into masonry or furniture.

Specifications

• Model: 089752
• Color: Brushed brown steel
• Number of modules: 4
• Number of outlets: 2
• Material: Metal
• Surface protection: Brushed
• Surface finish: Matt
• Halogen-free: Yes
• With hinged lid: Yes
• Mounting type: Flush-mounted
• Fastening type: Screw mounting
• Suitable for mounting on a bottom duct box: Yes
• Mounting direction: Horizontal
• Number of units horizontally: 2
• Number of units vertically: 1
• IP class: IP44 (protection against water splashes and small solid particles)
• Impact resistance: IK08 (high resistance to mechanical impact)
• Width: 172 mm
• Height: 86 mm
• Depth: 41 mm
• Built-in height: 28 mm
• Operating temperature: -5-35 °C
• Storage temperature: -10-70 °C

Manufacturer

🔗 Manufacturer's link

Documents / Certificates

🔗 CE Declaration

🔗 Technical data sheet

Frequently Asked Questions (FAQ)

How is this floor box installed?

The floor box is designed for flush mounting. For installation into masonry, a separately purchased concrete box (model 081988) is used, and for installation into furniture or plaster, a back box (model 080188) is used.

What does the IP44 rating mean for this floor box?

The IP44 rating means that the floor box is protected against solid particles larger than 1 mm and against water splashes from any direction, making it suitable for use in environments where moisture exposure may occur.

Can additional functions be integrated into the box?

Yes, this floor box has the option to integrate LED lighting, increasing its visibility and aesthetics.
