Plastic case Plastim PP3010 (700x500x250, grey, IP65, IK08)

Description

Plastim PP3010 – a plastic distribution case for electrical installations. This HB ABS material case is designed for operation in commercial and industrial facilities, ensuring reliable protection of electrical components. Its IP65 protection class guarantees complete resistance to dust and protection against water jets, extending the service life of the equipment inside and ensuring stable operation.

Specification

• Dimensions: 700x500x250 mm
• Material: HB ABS (ensures impact resistance)
• Color: RAL7035 grey
• Protection class (IP): IP65 (protection against dust and water jets)
• Mechanical resistance class (IK): IK08 (impact resistance up to 5 J)
• Rated voltage: up to 690V
• Maximum current: up to 800A
• Mounting plate: 1 mm galvanized steel

Manufacturer

🔗 Manufacturer's link

Documents / Certificates

🔗 CE declaration

🔗 Technical data sheet
