Power cable Prysmian Group XPK-HF C Pro 3x1.5 mm² copper XLPE LSZH CPR Cca 0.6/1 kV solid.

Description

Prysmian Group XPK-HF C Pro 3x1.5 mm² is a power cable, versatile for indoor and outdoor applications. Its copper 3x1.5 mm² core configuration ensures efficient current transmission in low-power circuits, while XLPE insulation and LSZH sheath guarantee fire resistance and do not emit toxic fumes during combustion (Cca-s1,d1,a1 fire resistance class). This solid core cable is suitable for use in low-voltage electrical networks.

Specification

• Model: XPK-HF C Pro 3x1.5 mm²
• Number of cores and cross-section: 3 cores of 1.5 mm² (ensures adequate current capacity for low-power circuits).
• Core material: Copper (features excellent electrical conductivity and durability).
• Core type: Solid (a continuous core structure increases mechanical resistance).
• Cable shape: Round (facilitates installation in pipes or conduits).
• Insulation type: XLPE (reinforced polyethylene insulation ensures high resistance to heat and moisture).
• Sheath material: LSZH (Low Smoke Zero Halogen – reduces the emission of smoke and harmful gases in case of fire).
• Rated voltage: 0.6/1 kV (for safe use in low-voltage systems up to 1000 V).
• Fire resistance class (CPR): Cca-s1,d1,a1 (ensures high fire resistance and minimal smoke and droplet formation).
• Operating temperature range: From -15 °C to +90 °C (allows the cable to be operated in a wide ambient temperature range).
• UV resistance: Present (ensures longevity when installed outdoors).
• Application: Universal, designed for installation both indoors and outdoors.
• Sales: The cable is sold by the meter, with the price indicated per 1 m. When purchasing a full reel, an additional drum fee applies.

Documents / Certificates

🔗 Declaration of Performance
