Flexible cable Elmat HSLH-JZ 4x0.75 mm² copper LSZH CPR Cca 300/500 V.

Description

The Elmat HSLH-JZ 4x0.75 is a flexible copper multi-core cable designed for energy transmission and control systems. This model features a CPR Cca-s1,d1,a1 fire class, which means high fire resistance and minimal smoke and burning droplet emission in case of an emergency, thus ensuring greater safety. It is suitable for use in low-voltage electrical networks and meets stringent installation requirements.

Specification

• Type: Flexible copper multi-core cable
• Model: HSLH-JZ 4x0.75
• Number of cores and cross-section: 4x0.75 mm²
• Color: Grey
• Rated voltage: 300/500 V (indicates the maximum permissible operating voltage, ensuring reliable electrical power transmission)
• Halogen content: Halogen-free (LSZH) (ensures low emission of corrosive gases and smoke during a fire)
• Fire class: Cca-s1,d1,a1 (CPR Cca) (indicates high fire resistance and minimal smoke and droplet emission)
• Length: 500 m (free drum)

Documents / Certificates

🔗 Declaration of Performance

🔗 CE Declaration
