Flexible cable elpar hdgs ph90 3x1.5 mm² copper lszh cpr cca 300/600v

Description

Elpar HDGS PH90 3x1.5 mm² copper LSZH CPR Cca 300/600V – a flexible cable designed for low-voltage distribution networks. This cable, featuring 3 copper conductors with a 1.5 mm² cross-section, ensures reliable electrical power transmission. Due to its LSZH (Low Smoke Zero Halogen) properties, it does not emit much smoke or harmful gases in case of fire, thus meeting low-voltage installation requirements and being safe to use.

Specification

• Model: HDGS PH90
• Type: Flexible Cable
• Number and Type of Conductors: 3 copper conductors
• Conductor Cross-section: 1.5 mm², ensuring adequate current capacity.
• Insulation Material: LSZH (Low Smoke Zero Halogen), reducing smoke and toxic gas emissions in case of fire.
• Fire Performance Class: CPR Cca, complying with stringent Construction Products Regulation requirements.
• Rated Voltage: 300/600 V, suitable for low-voltage electrical systems.

Documents / Certificates

🔗 Declaration of Performance

🔗 Datasheet
