Legrand 310184 UPS (tower, 800VA/480W)

The Legrand 310184 Uninterruptible Power Supply (UPS) is a reliable tower-type device designed to protect electronic equipment from power disruptions. With an 800VA/480W power capacity, this model ensures a stable energy supply and protection for computers, network equipment, and other sensitive electronics. It is ideally suited for small businesses or home offices that require uninterrupted operation of critical systems.

Product Information

General Information

• UPS Technology: Line-interactive
• Design Type: Freestanding model
• With Socket(s): Yes
• Includes Battery(ies): Yes
• Managed Load Type: Universal

Power Parameters

• Input Voltage: 170-280 V
• Primary Frequency: 45-65 Hz
• Number of Primary Phases: 1
• Output Voltage: 207-253 V
• Secondary Frequency: 49-61 Hz
• Active Output Power: 480 W
• Apparent Output Power: 800 VA
• Output Power Factor: 0.6
• Overall Efficiency: 97 %
• Transfer Time at Full Load: 0 min

Connections

• USB Interface: Yes
• With RS-232 Communication Interface: Yes
• Number of Secondary Phases: 1
• SNMP: No
• Input Connector: C14
• Number of C13 Output Connectors: 2
• Number of C19 Output Connectors: 0
• Number of Output Connectors with Protective Contact CEE 7/3 (Type F): 2
• Number of Output Connectors French Standard (Type E): 0
• Potential-Free Switch Contact: No

Physical Parameters

• Height: 173 mm
• Width: 148 mm
• Depth: 380 mm
• Weight: 10.5 kg
• Voltage Type: AC
• IP Class: Not applicable

Environmental Conditions

• Operating Temperature: 0-40 °C
• Storage Temperature: 0-40 °C
• Sound Level: 40 dB

Additional Features

• Suitable for Network Management: No
• Automatic Shutdown Function: No
• 1 x Schuko, USB
• Smart LED Bar
• Modern Black/White Design
• Graphical LED Bar for Battery Level Indication, Mute Button for Audible Alarm
