Legrand 310187 UPS (tower, 1000VA/600W)

The Legrand 310187 UPS is a Line-interactive uninterruptible power supply, designed to ensure reliable protection of electronic equipment from voltage fluctuations and interruptions. This free-standing device features 1000 VA / 600 W power, making it suitable for office computers, network equipment, and other sensitive electronics. With a built-in battery and communication interfaces, the Legrand UPS model provides stable power and the ability to monitor the device's status.

Product Information

General Features

• UPS technology: Line-interactive
• Design type: Free-standing model
• Controlled load type: Universal
• With outlets: Yes
• Battery included: Yes
• Smart LED bar
• Modern black/white design
• Graphic LED bar for battery level indication, audible alarm mute button

Input Parameters

• Input voltage: 170-280 V
• Input frequency: 45-65 Hz
• Number of input phases: 1
• Input connector: C14

Output Parameters

• Output voltage: 207-253 V
• Output frequency: 49-61 Hz
• Active output power: 600 W
• Apparent output power: 1000 VA
• Number of output phases: 1
• Voltage type: AC
• Switching time at full load: 0 min
• Output power factor: 0.6
• Overall efficiency: 97 %

Connections and Interfaces

• USB interface: Yes
• RS-232 communication interface: Yes
• SNMP: No
• Dry contact: No
• Automatic shutdown function: No
• Number of C13 outlets: 2
• Number of C19 outlets: 0
• Number of CEE 7/3 (Type F) protective contact outlets: 2
• Number of hardwired output connections: 0
• Number of French standard (Type E) output connectors: 0
• Connections: 2xSchuko + 2xC14 + 1xUSB

Dimensions and Weight

• Height: 173 mm
• Width: 148 mm
• Depth: 380 mm
• Weight: 9 kg

Environmental Conditions and Additional Features

• IP rating: Not applicable
• Operating temperature: 0-40 °C
• Storage temperature: 0-40 °C
• Noise level: 40 dB
• Suitable for network management: No
