EV charging plug Duosida Type 1 (Female), 32A, single-phase

The EV plug is designed to create your own EV charger, choosing the desired cable length and connectors.


Technical specifications:
Plug type: “SAE J1772”, “Type1” (“Japan/US”), “Yazaki”.
Rated current: 32A.
Operating voltage: 240V AC (single-phase).
Maximum charging power: 7.4 kW.
Material: Thermoplastic, fire resistance “UL94 V-0”.
Cable contacts: Copper alloy, silver plating.
Adaptable cable dimensions: 3x6mm²+ 2x0.5mm² (1-phase) / 3x10AWG+1x18AWG.
Number of contacts: 5.
Safety class: “IP44”.
Certifications: “CE”, “TUV”.
Colour: Black / white.


Type1 is suitable for the following electric vehicles:
Chevrolet Bolt EV.
Chevrolet Spark EV.
Chevrolet Volt EV.
Citroen C-Zero EV.
Citroen E-Berlingo Multispace EV.
Fiat 500e EV.
Fisker Karma EV.
Ford C-Max Energi EV.
Ford Focus EV.
Ford Fusion Energi PHEV.
Ford Transit Charging Cable.
Honda Clarity EV.
Hyundai i10 EV.
Hyundai Sonata EV.
Kia Soul EV.
Mitsubishi Outlander PHEV.
Mitsubishi-I Mi EV.
Nissan e-NV200 Combi Van EV.
Nissan NV200 SE Van EV.
Peugeot iOn EV.
Peugeot Partner EV.
Renault Fluence EV (“Pre-2014”).
Renault Kangoo Phase 1 EV.
Toyota Auris EV.
Toyota Prius EV (“Pre-2017”).
Vauxhall Ampera EV.
(The list may be incomplete).


Warranty: 24 months.
