Fire-resistant shielded halogen-free cable Bitner HTKSHekw 2x2x0.8mm
zoom_out_map
Fire-resistant shielded halogen-free cable Bitner HTKSHekw 2x2x0.8mm

Fire-resistant shielded halogen-free cable Bitner HTKSHekw 2x2x0.8mm

€ 102,74
Delivery is always on time  Delivery is always on time
Order product today by 12:00
And we will send your order today.
Time left:
03
:
00
:
00
Quantity

  • Temperature range:
    • Fixed installation: -30°C up to 80°C
    • During installation: -5°C up to 50°C
  • Operating voltage: 225V
  • Test voltage: AC 1500 V DC 2250 V
  • Insulation resistance (minimum): 500 MΩ*km
  • Loop resistance at 20°C (maximum):
    • 0,8 mm - 75 Ω/km
    • 1,0 mm - 48 Ω/km
    • 1,4 mm - 26,6 Ω/km
    • 1,8 mm - 14,96 Ω/km
    • 2,3 mm - 9,6 Ω/km
    • 2,8 mm - 6,4 Ω/km
  • Mutual pair capacitance at 1kHz (maximum):
    • Unscreened cable: 120 nF/km
    • Screened cable: 150 nF/km
  • Inductance: 0,7 mH/km
  • Minimum bending radius: 10 x Ø
