Fire-resistant shielded non-flammable cable Bitner HTKSHekw FE180/Ph120 E90 2x2x0.8mm.
zoom_out_map
Fire-resistant shielded non-flammable cable Bitner HTKSHekw FE180/Ph120 E90 2x2x0.8mm.

Fire-resistant shielded non-flammable cable Bitner HTKSHekw FE180/Ph120 E90 2x2x0.8mm.

€ 164,16
Delivery is always on time  Delivery is always on time
Order product today by 12:00
And we will send your order today.
Time left:
05
:
00
:
00
Quantity

  • Temperature range:
    • Fixed installation: -30°C up to 80°C
    • During installation: -5°C up to 50°C
  • Operating voltage: 225V
  • Test voltage: AC 1500 V DC 2250 V
  • Insulation resistance (minimum): 500 MΩ*km
  • Loop resistance at 20°C (maximum):
    • 0.8 mm - 75 Ω/km
    • 1.0 mm - 48 Ω/km
    • 1.4 mm - 26.6 Ω/km
    • 1.8 mm - 14.96 Ω/km
    • 2.3 mm - 9.6 Ω/km
    • 2.8 mm - 6.4 Ω/km
  • Mutual capacitance of pair at 1kHz (maximum):
    • Unscreened cable: 120 nF/km
    • Screened cable: 150 nF/km
  • Inductance: 0.7 mH/km
  • Min. bending radius: 10 x Ø
