Network cable Dahua UTP5e PFM920I-5EUN (Cat5e, HDPE, PoE, PVC, reel 305m)

In stock: Yes

€ 122,72

Delivery is always on time

Order product today by 12:00

And we will send your order today.

Time left:

Quantity

Product description

Material Oxygen free copper (99.97% purity)
Diameter 0.45 mm ± 0.01 mm
Material HDPE
Min. average thickness 0.18 mm
Diameter 0.81mm±0.1mm
Color (4 pairs) Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Material Polyester
Specification 500D
Material PVC
Min. average thickness 0.5 mm
Diameter 4.7 mm ± 0.3 mm
Color White
Max. DC resistance per conductor 12Ω/100 m
Min. insulation resistance 5000MΩ·km
Max. DC resistance unbalance 2% (pair intra), 4% (pairs inter)
Dielectric strength limit No breakdown with 1KV DC for 1 min
Characteristic impedance 100 ± 15Ω
Near-end crosstalk ≥35.30 dB/100 m@100 MHz
Max. attenuation 24.2 dB/100 m@100 MHz
Return loss level ≥20.1 dB/100 m@100 MHz
Tensile strength Sheath≥13.5 MPa, insulation≥16 MPa
Elongation at break Sheath≥150%, insulation≥300%
Installation bending radius >8 times of outer cable diameter
Conductor elongation at break ≥10%
Insulation shrinkage ≤5%
Insulation color migration resistance No migration
Sheath tensile strength and elongation after aging ≥12.5 MPa, ≥100%
Low temperature bending test No cracking after the test
Thermal shock test No cracking after the test
Operating temperature –20°C to +60°C (–4°F to 140°F)
Installation temperature 0°C to +50°C (32°F to 122°F)
Storage temperature and humidity –10°C to +40°C (14°F to 104°F), <60% (RH)
Vertical flame propagation test Comply with IEC 60332-1-2
Cable length 305.0 m (1000.66 ft) ± 1.5 m (4.92 ft)
Inner box dimensions 364.0 mm × 364.0 mm × 216.0 mm(14.33" × 14.33" × 8.50") (L × W × H)
Packaging method 305.0 m (1000.66 ft) a carton, 45 pcs/pallet
Weight without packaging ≥7.0 kg (15.43 lb)
Weight with packaging ≥8.0 kg (17.64 lb)
Implemented standards Q/DXJ 067-2019, EN50575-2014
Certification CPR Eca
