East EA902PSRT UPS (rack, LCD, 2000VA/1800W, EPO version)

This Uninterruptible Power Supply (UPS) East EA902PSRT, with a capacity of 2000 VA / 1800 W, is designed to reliably protect sensitive equipment from power grid disturbances. It is installed in standard rack cabinets and features an LCD screen, allowing easy monitoring of system status and parameters. Thanks to the integrated EPO (Emergency Power Off) function, this device ensures quick and safe system shutdown in critical situations, making it suitable for data centers and server rooms.

Product Information

Key Parameters

• Capacity: 2000 VA / 1800 W
• Waveform: Mains mode: pure sine wave; Battery mode: simulated sine wave
• Transfer time: 2–7 ms (typical), 10 ms (max.)

Input Specifications

• Input voltage: 110–176 Vac (linear derating between 50% and 100% load); 176–280 Vac (no derating); 280–300 Vac (50% derating)
• Input frequency: 40–70 Hz (auto-sensing)

Output Specifications

• Output voltage: 208 / 220 / 230 / 240 Vac (configurable via LCD)
• Frequency: 45–55 Hz or 55–65 Hz (synchronized range); 50 / 60 Hz ± 0.1 Hz (battery mode)
• Connectors: 6 x C13

Battery and Protection

• Battery: 4×9 Ah
• Protection: Short circuit, overload, overheat, battery discharge, and fan test protection
• EPO: Emergency Power Off

Physical and Environmental Characteristics

• Relative humidity: 0–95% (non-condensing)
• Noise level: ≤ 50 dB (1 m)
• Dimensions: 440 × 658 × 88 mm
• Package dimensions: 545 × 782 × 198 mm

Downloads / Certifications

📄CE Declaration

📄Specification

📄User Manual
