ARCTIC P12 PRO PWM PST Case Fan, 4-pin, 120mm, White

Case Fan P12 Pro PST, 4-pin, 120mm, White


Features:
Efficient Performance under High Air Resistance. Thanks to high static pressure, “Pro” series fans effectively push air through tight spaces. This makes them ideal for radiators, perforated panels, and mesh filters.
PST – PWM-based Synchronized Fan Control. An additional PWM connector allows multiple fans to be synchronized in series using a single connection.
Optimized Bearing and Spindle Design (FDB): The fluid dynamic bearing, combined with an extended spindle, ensures quieter operation by distributing pressure more evenly and reducing vibrations.
Automatic Balancing: An automatic measurement and balance correction system ensures exceptional fan impeller precision and smooth operation, making the fan spin evenly without extraneous vibrations and noise, and reducing bearing load.
Advanced Microcontroller reduces motor noise, compensates for load fluctuations, and prevents high currents during startup or incorrect polarity connections.
More Power, Less Noise. The fan provides higher performance at low speeds, increased airflow, and static pressure, with a noise level of only 25 dB(A) – ideal for quiet and powerful cooling.
6-Year Warranty. Excellent long-term testing results, even under extremely unfavorable conditions, allow us to ensure that these products are characterized by both quality and durability, thus providing a 6-year manufacturer's warranty.
Maximum Performance: The improved fan blade design ensures an optimal balance of performance and smooth operation. Smaller gaps allow for higher static pressure and maximum airflow efficiency.


Technical Specifications:
Speed: 600-3000 RPM PWM controlled (0 RPM below 5% PWM).
Airflow: 77 CFM / 131 m³/h.
Static Pressure: 6.9 (mm / H2O).
Bearing: Fluid Dynamic Bearing.
Voltage/Current: 0.33A/ 12V DC.
Connector: 4-pin + 4-pin socket.
Cable Length: 400mm+80mm.
Dimensions: 120x120x25 mm.
Color: White.
Weight: 185 g.


Warranty: 6 years.
