Residual current circuit breaker with automatic switch Legrand 411158 (2P, 16A, C, 30mA, 10kA, AC)
zoom_out_map
Residual current circuit breaker with automatic switch Legrand 411158 (2P, 16A, C, 30mA, 10kA, AC)

Residual current circuit breaker with automatic switch Legrand 411158 (2P, 16A, C, 30mA, 10kA, AC)

€ 70,80
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Number of poles (total)2
  • Number of protected poles2
  • Rated voltage230 V
  • Rated current16 A
  • Rated fault current0.03 A
  • Leakage current typeAC
  • Current limiting class3
  • Rated short-circuit breaking capacity according to EN 610096 kA
  • Rated short-circuit breaking capacity according to IEC 60947-210 kA
  • Rated short-circuit breaking capacity Icn according to EN 61009-16 kA
  • Surge current capacity0.25 kA
  • Voltage typeAC
  • Frequency50 Hz
  • Release characteristicC
  • Concurrently switching neutral conductorYes
  • With interlocking deviceYes
  • Pollution degree2
  • Width in number of modular spacings4
  • Built-in depth44 mm
  • Flush-mounted installationYes
  • Anti-nuisance tripping versionNo
  • Degree of protection (IP)IP20
  • Connectable conductor cross section solid-core1-35 mm²
  • Connectable conductor cross section multi-wired1-25 mm²
