Residual current circuit breaker with overcurrent protection Hager AD960J (2P, 10A, type A, 30mA, 230V)
zoom_out_map
Residual current circuit breaker with overcurrent protection Hager AD960J (2P, 10A, type A, 30mA, 230V)

Residual current circuit breaker with overcurrent protection Hager AD960J (2P, 10A, type A, 30mA, 230V)

€ 61,90
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • General
  • Product nameHager AD960J
  • TypeRCBO (Residual Current Circuit Breaker with Overcurrent Protection)
  • Pole configuration1P+N
  • Tripping curveC
  • Rated current10 A
  • Rated residual operating current Idn30 mA
  • Residual current typeA
  • Rated short-circuit breaking capacity Icn (230 V AC, IEC 60898-1)6 kA
  • Rated insulation voltage Ui500 V
  • Rated impulse withstand voltage Uimp4,000 V
  • Rated operational voltage Ue240 V AC
  • Maximum operating voltage240 V
  • Overvoltage category (IEC 60947-1)3
  • Correction factor of rating current (2 devices side by side)1
  • Correction factor (3 devices side by side)0.95
  • Correction factor (4–5 devices side by side)0.90
  • Correction factor (6 devices side by side)0.85
  • Thermal operation threshold (AC)1.13 – 1.45 A
  • Ingress Protection (IP) classIP2X
  • Frequency50 Hz
  • Max. altitude2,000 m
  • Class of energy limitation I²t3
  • Operating temperature–25 to +40 °C
  • Storage/transport temperature–25 to +70 °C
  • Electrical endurance2,000 cycles
  • Mechanical endurance2,000 operations
  • Total power loss at In3.40 W
  • Connection typeScrew terminal (top), Biconnect (bottom)
  • Nominal tightening torque2.10 Nm
  • Conductor cross-section (flexible)1–16 mm²
  • Conductor cross-section (rigid)1–25 mm²
  • Number of modules2
  • Height83 mm
  • Width35 mm
  • Depth68 mm
