HIKVISION UPS DS-UPS02K48-R/TJS(O-STD)/EU/IEC (Rack/Tower, LCD, 2000VA/1800W)
zoom_out_map
HIKVISION UPS DS-UPS02K48-R/TJS(O-STD)/EU/IEC (Rack/Tower, LCD, 2000VA/1800W)

HIKVISION UPS DS-UPS02K48-R/TJS(O-STD)/EU/IEC (Rack/Tower, LCD, 2000VA/1800W)

€ 629,90
Delivery is always on time  Delivery is always on time
Order product today
And we will send your order tomorrow.
Quantity

  • Battery
  • Battery Number4
  • Battery TypeValve Regulated Lead Acid (VRLA)
  • Capacity (Standard Unit)12V/9Ah
  • Charging Current (Max.)1A
  • DC System Voltage (VDC)48V
  • Expandable RuntimeYes, External battery pack: DS-UPSB0948B-R/TJC
  • Typical Backup TimeView Runtime Graph
  • Typical Recharging Time4 hours (To 90% of full capacity)
  • Efficiency
  • AC Mode91%
  • Battery Mode87%
  • Environment
  • Altitude<1500m, derating required when>1500m
  • Humidity Range20~95%RH @ 0~40°C (Non condensing)
  • Noise Level<50dB at 1 Meter
  • Operating Temperature0°C~40°C
  • Storage Temperature-25°C~55°C
  • Indicator
  • AlarmBattery mode/Battery low voltage /Overload/Fault
  • LCD displayInput voltage, Input frequency, Output voltage, Output frequency, Load percentage, Battery voltage, Inner temperature & Remaining battery backup time
  • Input
  • Input Frequency40~70Hz (50/60Hz Auto-Sensing)
  • Input Voltage Range110~300Vac (176~264Vac @ 100% load)
  • Nominal Voltage208/220/230/240Vac
  • PhaseSingle Phase
  • Power factor≥0.99
  • Output
  • Crest factor3:1
  • Harmonic distortion (THDv)≤3% Linear load ≤5% Non linear load
  • Output FrequencyOnline mode: 46~54Hz or 56~64Hz Bat. Mode: (50/60±0.1%)Hz
  • Output SocketsIEC panel/EU panel/UK panel/US panel Optional
  • Output Voltage208/220/230/240Vac
  • Output WaveformPure Sinewave
  • Power factor 0.9
  • Transfer TimeAC mode to Bat.mode: 0ms Inverter to Bypass: 4ms (Typical)
  • Physical
  • Dimension W x D x H (mm)440 x 460 x 86.5
  • Net weight (kg)19.5
  • Power
  • UPS Capacity 2000 VA / 1800 W
  • Standards
  • EMCCE-EMC, IEC/EN 62040-2, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8
  • SafetyCE-LVD, IEC/EN 62040-1, IEC/EN 62477-1
